Improved visualization and surgical access during anterior hip replacement

off table_4x.png

Firmly holds an x-ray cassette under the patient's pelvis

Compatible with any standard OR table (US/EU/JPN/Denyer)

This tabletop accessory improves surgical access and allows x-ray cassettes to be used with standard OR tables for full pelvic x-ray visualization during anterior THR. Cutouts under the hip allow for soft-tissue fallout, easing surgical access to the acetabulum. The removable, adjustable femoral support offers four fulcrum height settings to lift the proximal end of the femur for optimal exposure.

Features

Exceptional Visualization

The ratcheting x-ray cassette holder allows digital x-ray

cassettes to be swiftly and precisely positioned under the patient’s pelvis - enabling intraoperative, undistorted full pelvic x-rays.



Exceptional visualization x-ray cassette holder under pelvis for leg length comparison

Improved Acetabular Access

Cutouts under the hip allow for soft tissue fallout –easing surgical access to the acetabulum.

Screen Shot 2022-05-10 at 10.14.20 AM.png

Highly Configurable

The asymmetric femoral support provides 4 height settings – simply remove the support, rotate 90°, and reinstall to adjust height. This allows the surgeon to fine-tune the fulcrum point for femoral exposure.

mpx highly configuratble.jpg
Features MP XRAYCER
Surgeon Testmonial

To make [the ARCH] more effective yet, the addition of the MP XRAYCER makes sure you leave the OR 100% confident in your implant positioning, alignment, and leg lengths.



Austin McPhilamy, MD

Specifications
MP XRAYCER for surgical access to the acetabulum

X-ray Cassette /Grid Assembly Max. Size:

W: 450 mm L: 3 80 mm H: 20 mm

Femoral Support Height:

4 settings: 20mm, 40mm, 60mm, or 80 mm

Width:

19.7 in (50 cm)

Length:

41.7 in ( 106 cm)


Weight:

33 lb ( 15 kg}


Patient Weight Capacity:

500 lb (227 kg)*

*If the safe working load of the OR table used is lower than this, the OR table patient weight limit takes priority.

Specifications MP XRAYCER
